Foam Sheet Jointing Machine
GY-1300-JM
It is an electromagnetic system that bonds EVA and PF foam cut into thin thicknesses with heat to create a roll product.
Features
- The sheet is fully bonded, cut, and produced as a roll product.
- It maximizes productivity compared to manual adhesion.
- The adhesive part, that is, both edges of the foam can be perfectly adhered without opening.
- Laminating is very convenient because there is no step difference in the adhesive area.
- Roll work is convenient by cutting both edges of the foam at the same time as adhesion.
- Because it adheres to a thin sheet, it doesn't require a large amount of equipment.
Technical data
| Model | GY-1300-JM |
|---|---|
| Available material width (max) | 1200mm |
| Available material length (max) | 2400mm |
| Available material length (max) | 5-12mm |
| Electrical power capacity | 6kw, Approx. |
| Electrical requirements | 380V, 60/50Hz, 3Ph |
| Net / Gross weight | 1500 / 1900kgs |
| Footprint | L5220 x W1460 x H1505mm |
